SWITCH FORTISWITCH FORTNET -148F-POE L2+ MANAGEMENT SWITCH WITH 48X GE PORT + 4X SFP+ PORT + 1X RJ45 CONSOLE. PORT 1- 24 ARE POE PORTS WITH AUTOMATIC MAX 370W POE OUTPUT LIMIT (24 PORT 802.3AF OR 12 PORT 802.3AT)
SWITCH FORTISWITCH FORTNET -148F-POE
Primary Information
Network Device Type:
Switch
Model:
FortiSwitch 148F-POE
Form Factor:
1RU
Connectivity Technology:
Wired
Data Transfer Rate:
10 Gbps
Networking / Ports Qty:
54
Data Link Protocol:
Gigabit Ethernet
RAM / Total Installed Size:
512 MB
Flash Memory / Installed Size:
64 MB
Networking Compliant Standards:
802.1D, 802.1w, 802.1s
Media Layer Supported:
Layer 2, Layer 3
Power / Device Type:
Power Supply
Power Consumption Operational:
474.8 Watt
Max Power Consumption:
476.3 Watt
Power / Voltage Required:
100-240V AC, 50-60 Hz
MTBF:
> 10 years
Features:
Support FortiLink FortiGate in HA Cluster. LAG support for FortiLink Connection. Active-Active Split LAG from FortiGate to FortiSwitches for Advanced Redundancy.
Network
Power Over Ethernet (PoE) Support:
Y
PoE Power Consumption:
370 W
MAC Address Table Size:
32 K
Jumbo Frame Support:
Y
Remote Management Protocol:
DHCP; IPv4; VLAN
Routing Protocol:
OSPFv2, RIPv2, VRRP, BGP, ISIS
Authentication Method:
RADIUS
SFP+ Ports:
4
Interfaces:
RJ45;SFP+;RJ-45 Serial Console
Interfaces / Ports
Interfaces:
RJ45;SFP+;RJ-45 Serial Console
SFP+ Ports:
4
Dimensions&Miscellaneous
Width:
17.32 Inch
Depth:
12.20 Inch
Height:
1.73 Inch
Weight:
4.68 Kg
Special Feature
Min Operating Temperature:
0 Celsius
Max Operating Temperature:
45 Celsius
Min Storage Temperature:
-20 Celsius
Max Storage Temperature:
70 Celsius
RoHS:
Y
COO:
Inquire
TAA compliance:
Inquire
Código UNSPSC
Código UNSPSC:
43222612
